项目名称
Name
|
技术参数
Technical
specification
|
|
机身高度
Machine height
|
1.87m
|
|
手臂举起状态
Arm raising:
|
手臂高度（最高点）
Arm height (Max.)
|
2200mm
|
|
手爪上沿高度
Height of upper claw edge
|
2185mm
|
|
最大直径
Max. Diameter
|
1800mm
|
|
手臂放下状态
Arm down
|
手爪高度(手臂最低点)
Gripper height (Lowest point of arm)
|
1485mm
|
|
最大直径
Max. Diameter
|
2080mm
|
|
手爪张口尺寸
Gripper opening
|
80mm
|
|
手爪闭口尺寸
Gripper closing
|
8mm
|
|
万向轮子高度
Height of universal wheel
|
170mm
|
|
机座底盘直径
Base chassis
diameter
|
1.2m
|
|
总重量
Total weight
|
1600kg
|
|
电机功率
Motor power
|
550W
|
|
电机额定转速
Motor rated speed
|
1390rpm
|
|
电机工作电压
Motor working
voltage
|
380V/50Hz, three- phase
|
|
液压工作压力
Hydraulic
working pressure
|
3～10MPa
|
|
液压流量
Hydraulic Flow Rate
|
≥40L/m
|
|
气源压力
Air pressure
|
0.7MPa
|
|
供电电源功率
Power supply
|
30KW
|
|
供电电源电压
Power
supply voltage:
|
380V/50Hz,
three- phase
|
