二级减压阀参数

名称	二级减压阀
型号	JYF-3.5MPa-3.5bar-0
进口通径	DN10
出口通径	DN10
进口压力	0.8～3.5MPa
出口压力	0～3.5bar (可调)
介质	空气、惰性气体、氢气
温度	-40～+67℃

Two stage pressure reducer

Name	Two stage pressure reducer
Model	JYF-3.5MPa-3.5bar-0
Inlet	DN10
Outlet	DN10
Inlet Pr.	0.8～3.5MPa
Outlet Pr.	0～3.5bar (Adjustable)
Medium	Air, inert gas, hydrogen
Temperature	-40～+67℃

介绍：

该阀是活塞式减压阀，适用于自动控制领域，出口压力响应时间快。适用于管路系统中有多种压力。进口设有50μ过滤网。
Introduction:

The valve is piston pressure reducer, suitable for automatic control, outlet pressure response time is fast. It is suitable for many medium pressures in the piping system. The inlet is provided with a 50μ filter.
